Thermal Conductive Pad

• Application
• Thermal interface for electronics

• Color
• Yellowish White

• Dimension (L*W*H)
• Custom sizes available, standard roll 20m

• Installation Guideline
• Apply between heat source and sink

• Material
• Acrylic with Ceramic Filler

• Process
• Laminated with PET film

• Product Type
• Thermal Pad

• Standard
• UL94 V-0, ASTM D149, ASTM C1113

• Surface Treatment
• PET Film Liner

• Thickness
• 1.5mm

• Equipment Type
• Heat Transfer Plates

• Application
• LED, Computer, Chemical Industry

• Brand Name
• AR TAPES AND PLASTICS

• Color
• Grey

• Design
• Rectangular sheet

• Dimension (L*W*H)
• 20x67x1 Millimeter (mm)

• Finish
• Smooth

• Humidity
• <95% RH (Operational)

• Installation Guideline
• Peel and position onto surface

• Material
• silicone

• Mounting Type
• Adhesive backing

• Process
• Extruded sheet

• Processing
• Die-cut

• Product Type
• Thetrmal pad

• Service Period
• Long-term continuous use

• Size
• 1mm

• Standard
• RoHS Compliant

• Surface Treatment
• Anti-static coated

• Technique
• Injection molded

• Temperature
• -40 C to +200 C Celsius (oC)

• Thickness
• 1 Millimeter (mm)

• Tolerance
• 0.2 mm Millimeter (mm)

• Usage
• Thermal Management

• Weight
• 10 Grams (g)

• Equipment Type
• Heat Transfer Plates

• Application
• LED, Computer, Chemical Industry

• Brand Name
• AR TAPES AND PLASTICS

• Color
• Grey

• Design
• Rectangular sheet

• Dimension (L*W*H)
• 20x67x2 Millimeter (mm)

• Finish
• Smooth

• Humidity
• <95% RH (Operational)

• Installation Guideline
• Peel and position onto surface

• Material
• silicone

• Mounting Type
• Adhesive backing

• Process
• Extruded sheet

• Processing
• Die-cut

• Product Type
• Thetrmal pad

• Service Period
• Long-term continuous use

• Size
• 2MM

• Standard
• RoHS Compliant

• Surface Treatment
• Anti-static coated

• Technique
• Injection molded

• Temperature
• -40 C to +200 C Celsius (oC)

• Thickness
• 2 Millimeter (mm)

• Tolerance
• 2 Millimeter (mm)

• Usage
• Thermal Management
